LMM0022 - Class IV Fiber Laser Marker 30W, 110x110mm
Increments of 1
Minimum of 1
Maximum of
Sale price
€4.750,00 EUR
-100%
Regular price
€0,00 EUR
Regular price
€4.750,00 EUR
Unit price
per
Couldn't load pickup availability
The new generation of compact laser markers offers advanced performance in a safe, ergonomic design. Thanks to its motorized opening and safety sensor, the LMM0022 ensures efficient and completely safe operation. Ideal for marking metals and industrial plastics*, it allows for precise engraving at speeds of up to 7000 mm/s and a minimum reproducible thickness of 0.02 mm.
*a preliminary test on a minimum area is recommended for each new material to be put into use
Main Features
✅ Adjustable 30W power, suitable for deep and detailed markings.
✅ Motorized opening with protection sensor, for safe use.
✅ Working field 110 x 110 mm, ideal for a wide range of applications.
✅ Motorized and manually adjustable Z-axis, for simple and effective focusing.
✅ Double laser pointer, which ensures optimal precision.
✅ Air-cooled, reducing maintenance requirements.
✅ Power supply 220V at 50Hz, compatible with the standard electrical network.
✅ EZCAD2 software included, for intuitive marking management.
✅ Robust and compact structure, with a weight of 75 kg and dimensions of 730 x 500 x 850 mm.
Workable Materials
🔹 Metals: stainless steel, carbon steel, aluminum, copper, brass, titanium, silver, gold.
🔹 Metal alloys: magnesium, zinc, and treated materials.
🔹 Industrial plastics*: ABS, PVC, PE, PP, HDPE, PC.
🔹 Anodized, painted and plated surfaces*.
Applications
✔ Industrial marking on metal and plastic components
✔ Engraving of logos, serial numbers, QR and bar codes
✔ Customization of professional objects and tools
✔ Electronics, automotive, mechanical and jewelry sectors
Advantages of Fiber Laser Technology
🔹 Indelible marking, resistant to solvents, abrasions and high temperatures.
🔹 High precision, with minimum details down to 0.02 mm.
🔹 High speed, up to 7000 mm/s, for optimized productivity.
🔹 Maximum safety, thanks to the protection sensor and motorized opening.
🔹 Low operating costs, with no consumables or frequent maintenance required.
Technical Specifications
Laser Power: 30W (adjustable)
Laser Type: Fiber Optic
Wavelength: 1064 nm
Working range: 110 x 110 mm
Minimum reproducible thickness: 0.02 mm
Marking speed: up to 7000 mm/s
Focus: Dual laser pointer
Z-axis: Motorized and manually adjustable
Security system: Protection sensor and motorized opening
Cooling: Air
Power supply: 220V, 50 Hz
Software: EZCAD2 included
Dimensions: 730 x 500 x 850 mm
Weight: 75 kg
| Weight | 75 Kg |
| Length | 750 mm |
| Length | 540 mm |
| Height | 870 mm |
